上海 Intel PRO/100 M Desktop Adapter 100M PCI 网卡

上海 Intel PRO/100 M Desktop Adapter 100M PCI 网卡

  • 上架时间:
    商品点击数:2805
  • 本店售价:面议 Inquiry
    用户评价: 969508902@qq.com
  • 购买数量:

商品描述:

商品属性

上海源深科技&服务器配件供应商

产品名称:Intel PRO/100 M Desktop Adapter 100M PCI 网卡

Feature Value
PCI bus compatibility PCI 2.2 specification
Connector RJ-45, 100BASE-TX
Power requirements PCI 5.0V ±5%
Interrupt INTA
LEDs 2 LEDs:
SPEED LED, = ON for 100Mbps
LNK/ACT = ON for Link, FLASHes with Activity
Duplex mode Half- or Full-duplex
Data Rate 10 or 100 Mbps
Transmit/Receive Buffer 6 Kbytes
Dimensions 2.00" x 4.7" measured without the bracket
Boot Rom 64kx8 FLASH installed, configured with Intel Boot Agent 3.0 (combined PXE/RPL image). 3.3V-powered FLASH device.
Operating temperature Temperature
   Operating 0 to +55 oC @ < 2 oC/min
   Non-operating -40 to +70 oC @ < 4 oC/min
Humidity 10% - 90%, non-condensing
Standards conformance IEEE 802.3
IEEE 802.3ac
IEEE 802.3z
IEEE 802.3x
IEEE 802.1p
IEEE 802.1Q
PCI 2.2 specification
Compliance & Certification
  • FCC Part 15, Subpart J, Class B/Canada ICES-003/Japan VCCI Class B/CISPR 22 Class B
  • UL Recognized
  • CE DECLARED COMPLIANCE: Council Directive 89/336/EEC when tested in a representative chassis via standards EN55022 and EN50082-1. Council Directive 72/23/EEC via standard EN60950 A1/A2/A3/A4/A11
Included Software Intel® PROSet configuration and diagnostics utility
Intel® Boot Agent
Intel® Priority Packet
Intel Teaming (Servers only)
MTBF 1,389,236 hours (~159 years

保修期限:保修一个月



感谢您惠顾源深科技,本公司备有全系列服务器配件,出售的配件都可以开具正规机打发票,如果无法在我们网站上找到自己需要的产品,可拨打下方的联系电话直接询问,谢谢!





联系人:杨 先 生

淘宝旺旺:点击这里给我发消息

QQ:
点击这里给我发消息 969508902

MSN:969508902@qq.com

手机:15900814815

上海源深科技 上海 Intel PRO/100 M Desktop Adapter 100M PCI 网卡 高清图片

上海源深科技 上海 Intel PRO/100 M Desktop Adapter 100M PCI 网卡 高清图片

上海源深科技 上海 Intel PRO/100 M Desktop Adapter 100M PCI 网卡 高清图片
