Product Name：服务器 CPU E5-2407 1356 SR0LR 2.20GHZ

Part Number： SR0LR

Essentials

• Product CollectionIntel® Xeon® Processor E5 Family
• Code NameProducts formerly Sandy Bridge EN
• Vertical SegmentServer
• Processor NumberE5-2407
• StatusDiscontinued
• Launch DateQ2'12
• Expected DiscontinuanceQ2'15
• Lithography32 nm
• Recommended Customer Price$250.00 - $251.00

Performance

• # of Cores4
• # of Threads4
• Processor Base Frequency2.20 GHz
• Cache10 MB SmartCache
• Bus Speed6.4 GT/s QPI
• # of QPI Links1
• TDP80 W
• VID Voltage Range0.6V-1.35V

Supplemental Information

• Embedded Options AvailableNo
• DatasheetView now

Memory Specifications

• Max Memory Size (dependent on memory type)384 GB
• Memory TypesDDR3 800/1066
• Max # of Memory Channels3
• Max Memory Bandwidth25 GB/s
• ECC Memory Supported ^‡Yes

Expansion Options

• Scalability2S Only
• PCI Express Revision3.0
• Max # of PCI Express Lanes24

Package Specifications

• Sockets SupportedFCLGA1356
• Max CPU Configuration2
• Package Size45mm x 42.5mm
• Low Halogen Options AvailableSee MDDS

Advanced Technologies

• Intel® Turbo Boost Technology ^‡No
• Intel® Hyper-Threading Technology ^‡No
• Intel® Virtualization Technology (VT-x) ^‡Yes
• Intel® Virtualization Technology for Directed I/O (VT-d) ^‡Yes
• Intel® VT-x with Extended Page Tables (EPT) ^‡Yes
• Intel® 64 ^‡Yes
• Instruction Set64-bit
• Instruction Set ExtensionsIntel® AVX
• Idle StatesYes
• Enhanced Intel SpeedStep® TechnologyYes
• Intel® Demand Based SwitchingYes
• Thermal Monitoring TechnologiesYes
• Intel® Flex Memory AccessNo
• Intel® Identity Protection Technology ^‡No



Security & Reliability

• Intel® AES New InstructionsYes
• Intel® Trusted Execution Technology ^‡Yes
• Execute Disable Bit ^‡Yes

Condition：Used

Warranty：30 days
