Product Name：Data Acquisition board DAP 5200a DAP5200a/626

Part Number： DAP5200a/626

DAP 5200a/626 Specifications

General Specifications
Dimensions	12.28 inches x 4.2 inches
Power requirements	+5V, 7.0 Amps
Operating temperature	0-40 degrees Celsius
Accuracy of crystal clocks	100 parts per million
Type of A/D converter	Successive Approximation
Input
Analog Inputs	16
Expandable to	512
Voltage Ranges	0 to +5 volts, -2.5 to +2.5 volts, -5 to +5 volts, -10 to +10 volts
Samples (x 1000) per second*	800
Time increment (nanoseconds)	50
Minimum time interval (microseconds)*	1.25
Maximum Gain**	500
A/D Converters/Resolution (bits)	1/14
Digital Inputs (synchronous)	16
Expandable to	128
Samples (x 1000) per second	1666
Minimum time interval (microseconds)	0.6
Output
Analog Outputs	2
Expandable to	66
Voltage Ranges	0 to +5 volts, -2.5 to +2.5 volts, -5 to +5 volts, -10 to +10 volts, 0 to +10 volts
Updates (x 1000) per second*	833
Minimum time interval (microseconds)*	1.2
DAC Resolution (bits)	12
Digital Outputs	16
Expandable to	1024
Updates (x 1000) per second	1666
Minimum time interval (microseconds)	0.6
Microprocessor
Processor	AMD K6-III+
Clock Speed(MHz)	400
Onboard Operating System	DAPL 2000
RAM (Mbytes)	32
PC Interface Specifications
PC Interface	PCI
Samples (x1000) transferred per second***	1666
Samples (x1000) logged/second***	1666
DSP
Onboard DSP support	Enhanced



* To maintain full 14-bit resolution may require a lower sample rate when sampling more than one channel per ADC.
** Top sampling speeds are available only with gain=1. Gains of 10, 100, and 500 are also available.
*** Disk logging and data transfer rates vary with PC platform.

Condition：Used

Warranty：30 days
